High Speed PVC Rapid Rolling Warehouse Door

Stackable fast doors are designed for large doorways to withstand harsh working conditions and protect you from wind, dust and the harsh environments often exposed in mines, with perimeter seals to prevent dust from entering the building, unique folding technology, and metal reinforcement bars to keep straight in high winds, even in harsh conditions, providing better protection against wind.

product details

product description

Product Parameters

Application	Outdoor door
Maximum size (W * H)	8000mm*7000mm
Opening speed	0.8-1.5m/s
Closing speed	0.5-0.8m/s
Frame structure	Galvanized steel
Cover	Steel powder coating
Door cloth	PVDF high strength industrial base cloth, PVC window can be opened
Motor	0.75kW - 3.0KW Protection class: IP54
Control box	The control box is equipped with door opening button, emergency stop switch and a power switch Protection level: IP54
Safety device	Photoelectric protection on door rail, wireless safety soft bottom protection system
Wind resistance	Grade 12 (according to the size of the door)

Product features

This door is suitable for doors with strong wind pressure, higher, wider and faster, to win speed and efficiency for your logistics transport, without hindrance and without waiting. When time counts down to seconds, that gives you an advantage. Our high speed ensures smooth operation of your business and optimized logistics.

–Withstand strong wind loads

High strength wind resistant aluminum rod makes the wind pressure evenly distributed and has good wind resistance performance.

–Save energy

Short opening time and high sealing reduce its air flow and save energy. Effectively prevent dust, rain and snow from entering the room.

–Economic and durable

Corrosion-resistant fabric door curtain, long service life, low maintenance requirements.

–Low maintenance cost

The special structure of the wind rod makes the replacement of the door curtain very simple, and the damaged part of the door curtain can be replaced separately, reducing the maintenance cost.

Detail picture

Removable wind bar

The special structure of the wind pole can replace the damaged part of the door curtain separately when it is damaged, reducing the maintenance cost.

Safety photoelectric

The bottom of the door body is equipped with a standard photoelectric device. When the object or person passes through the infrared ray, the door will automatically stop falling and open to the position to avoid hitting pedestrians or goods.

Door curtain

The door curtain is composed of high strength industrial base cloth, high density low yarn polyester PVDF coated polyester mesh strip and streamlined glass fiber reinforced polyester.
